- Place of Origin
- WUXI (CHINA)
- Application
- Produce Metal products
- Classification
- Roll Forming Machine
- HS Number
- 8455221000
- Brand
- Qinghong,OEM
- Certification
- CE,UL,ISO
- Model
- SRT1100
- Serial
- QHMC-0017
Tag：roll forming machine, purlin machine, Roof panel Machine Roof and wall,roof panel roll forming machine,Downspout machine,portable downspout machine,downpipe machine
Main Specification
Raw Material | 0.3-0.8mm, G250Mpa-G550MPA | GI/GL/PPGI/PPGL |
|---|---|---|
De-coiler | 5Tons capacit/8tons/10tons | Manual/Electrical/ Hydraulic/Automatic |
Forming station | 1 Stations to form | forming by mold |
Cutting device | Automatic length measuring by encoder & PLC. | CR12Mov cutter blade |
Producing speed | 10 pcs/min | / |
Driven System | motor driven, feeding by servo feeding system | / |
Electrical control | PANASONIC/Siemens/ Customer requires | Touch screen & Button |
| Product Samples
